ADVANCE 70 CASEMENT WINDOWS

Modern technology and performance when it comes to the classic and timeless design of a casement window.

A fully integrated window and door profile system



Casement windows remain one of the most popular choice of window styles for the home. With so many configurations and variations in styles, colours, features and hardware, it's easy to see why customers continue to make casement windows, the popular choice. Our Advance 70 System offers superb qualities that will exceed expectation in terms of performance, aesthetics and environmental issues.

The ADVANCE 70 System is a fully-integrated, 70mm window and door profile system with both sculptured and chamfered variations. With double and triple glazing options the 5 chambered system has been intelligently designed to meet all requirements for improved thermal efficiency.

The ADVANCE 70 System benefits from large reinforcement chambers, where Selecta steel sections can be inserted for additional strength and rigidity when required, or increased thermal performance when combined with our RTR (Recycled Thermal Reinforcement) Bar.

The ADVANCE 70 System also offers enhanced security options and when correctly specified, casement windows are PAS24 and Secured by Design approved as standard.

TECHNICAL INFORMATION

1. PVCu FRAME

Multi-chambered for improved thermal efficiency and performance. Our PVCu frames are also 100% lead free!

2. HIGH SECURITY

PAS 24 & Secured By Design options available. Contact our Technical Department for further information.

3. GLAZING OPTIONS

Double and triple glazing options - 24mm, 28mm and 40mm.

4. RTR BAR

Use RTR (Recycled Thermal Reinforcement) Bar to increase the thermal performance of your windows.

5. GASKETS & SEALS

The gaskets and weatherseals are co-extruded within the frames to provide a weathertight seal - no heat loss or leaks!

FABRICATOR & FITTER FRIENDLY

Fully integrated chamfered and sculptured profile system designed for low stock holding, simple fabrication and easy installation.

  • 5 thermal chambers delivering optimal thermal performance to achieve A+ WER's.
  • Low sightline and high performance weather seals for improved insulation and weather protection.
  • 24mm, 28mm and 40mm glazing options to give you the ability to fabricate cost-effective, energy-efficient windows.
  • PAS24 and Secured by Design enhanced security options.
  • Fitter friendly knock-in beads for speedy installation and easier glazing
  • Available in 17 colourfoil finishes, which are available on one or boths sides, giving you 34 colour-ways.

TOP HUNG CASEMENT - (L) 1300mm x (H) 400mm

Air Permeability Classification

2

Water Tightness Classification

9A 600Pa

Resistance to Wind Resistance

A5

Exposure Category in Accordance with BS 6375 Part 1

2000 Pa

SIDE HUNG CASEMENT - (L) 600mm x (H) 1200mm

Air Permeability Classification

2

Water Tightness Classification

9A 600Pa

Resistance to Wind Resistance

A5

Exposure Category in Accordance with BS 6375 Part 1

2000 Pa

FIXED WINDOWS PART REINFORCED - (L) 1550mm x (H) 1550mm

Air Permeability Classification

2

Water Tightness Classification

9A 600Pa

Resistance to Wind Resistance

A5

Exposure Category in Accordance with BS 6375 Part 1

2000 Pa

MULTI-LIGHT WINDOWS, RTR OR STEEL TRANSOM / MULLION REINFORCEMENTS - (L) 1908mm x (H) 1330mm

Air Permeability Classification

2

Water Tightness Classification

9A 600Pa

Resistance to Wind Resistance

A5

Exposure Category in Accordance with BS 6375 Part 1

2000 Pa

BS 6375 PART 2 PERFORMANCE

Operating Forces

1

Impact Resistance

0

Mechanical Strength

3

Resistance to Repeated Opening and Closing

2

Static Torsion

3

Racking

3

ADVANCE 70 SCULPTURED AND CHAMFERED PVCu WINDOW SYSTEM

Fabrication and Installation

Fabricated and installed in accordance with the latest issue(s) of the Selecta Systems Ltd controlled manual(s)

System Description

The windows are double glazed only, laminated to glass P1A on one pane when required, internally beaded only, multi-point locking only, with welded transoms/mullions, tee and/or cruciform joints only. Windows are classified as W.

Ventilation

None

Window Types

Casement Windows, Fixed Windows, Multi-light windows comprising opening light(s) and/or fixed light(s)

28mm CHAMFERED BEAD

28mm SCULPTURED BEAD

40mm CHAMFERED BEAD

40mm SCULPTURED BEAD

BEADING OPTIONS TO COMPLIMENT ADVANCE 70 WINDOWS & DOORS

The ADVANCE 70 suite of profiles are available in both a chamfered and sculptured finish. To compliment the windows and doors, we provide a single lead bead with a co-extruded bubble gasket for excellent compression and weather seal.

The 28mm double glazing and 40mm triple glazing beads are available in both chamfered and sculptured to complimented the ADVANCE 70 suite of window and door profiles.

COLOUR OPTIONS

The Colourfoil Collection - 17 traditional and modern colourfoil finishes providing you with 34 colourways

Whilst many favour the bright appearance of brilliant white window frames, the emergence of coloured and more authentically grained profiles has captured the imagination of homeowners.

We offer a wide range of colour options, which have been put together to make the perfect palette for your next project. With 17 colourfoil finishes, available on the external or internal face only or both sides, the collection provides you with 34 colourways.

With modern and traditional shades complimented with authentic wood like finishes, colourfoil adds that finishing touch to any property. Our colour collections provide you with a fantastic palette of colour options for your next project, whatever the style, period or location.

The standard collection - Consists of the most popular colour combinations.

The premium collection - Consists of on-trend, traditional and modern colours and grained effects.

Add colour and elegance to your next project





STANDARD COLLECTION

PREMIUM COLLECTION

GRAINED AND SMOOTH COLOURS - WHAT'S THE DIFFERENCE?

Our grained effect colours have been designed to replicate the texture and look of wood. The texture is embossed within the coloured foil to add depth and realism to the colour shade or wood effect.

Our smooth effect colours have been created to replicate the smooth finish of aluminium. Dependant on the colour shade, this will either be complimented by a matt or semi-gloss finish to provide you with a clean finish.
