Panoramic door options have become a very popular choice with homeowners over the last few years. Selecta Systems have developed a revolutionary and innovative alternative to the bi-fold door that provides you with far more versatility.
BENEFITS
-
EASi-FOLD Doors, appropriately named because of the simplicity of operation, are a multi-pane set of doors with individually opening sashes with no visible hardware, only a handle on the master door.
-
EASi-FOLD Doors have individually opening and sliding sashes enabling easier handling when opening and closing, as each sash opens independently and glides effortlessly along a track, pivots and folds in to place against the master door, with very little force.
-
The ADVANCE 70 System is a fully-integrated, 70mm window and door profile system with both sculptured and chamfered variations. With double and triple glazing options the 5 chambered system has been intelligently designed to meet all requirements for improved thermal efficiency.
-
The ADVANCE 70 System benefits from large reinforcement chambers, where Selecta steel sections can be inserted for additional strength and rigidity when required, or increased thermal performance when combined with our RTR (Recycled Thermal Reinforcement) Bar.
-
The ADVANCE 70 EASi-FOLD Door System also offers enhanced security options and when correctly specified, residential doors are PAS24 and Secured by Design approved as standard.
FABRICATOR & FITTER FRIENDLY
100% LEAD FREE
INNOVATIVE DESIGN
ENHANCED SECURITY
EASi-FOLD and an easi-security solution to your next project
Our EASi-FOLD Doors have been rigorously tested to PAS 24 and Secured by Design, thus Building Regulation Document Q and SBD compliant.
Selecta Systems window and door products have been designed to conform with the standard for enhanced security performance, which includes testing for air and water tightness and wind loading.
Our BSi Kitemark accreditation reflects high industry standards, where tests expose the products to various extremes when installed, to demonstrate conformity, which reflects the premium quality of profiles that are extruded by the company.
TECHNICAL INFORMATION
1. PVCu FRAME
Multi-chambered for improved thermal efficiency and performance. Our PVCu frames are also 100% lead free!
2. HIGH SECURITY
PAS 24 & Secured By Design options available. Contact our Technical Department for further information.
3. GLAZING OPTIONS
Double and triple glazing options - 24mm, 28mm and 40mm.
4. RTR BAR
Use RTR (Recycled Thermal Reinforcement) Bar to increase the thermal performance of your windows.
5. EASi-SLIDE & EASi-FOLD
The EASi-FOLD sashes glide along a teflon track, lock in to a landing gate and fold against the master door - Effortless and simplistic!
FABRICATOR & FITTER FRIENDLY
Fully integrated chamfered and sculptured profile system designed for low stock holding, simple fabrication and easy installation.
PAS 24
Building Regulations Document Q Compliant
ENERGY RATING
Achieve a U Value of 1.4 W/(m2K) with a 28mm DGU
WEATHER TIGHTNESS
800Pa Exposure Category
SECURED BY DESIGN
Secured By Design Compliant
- KEY BENEFITS
- DATA - EASi-FOLD PVCu DOOR SYSTEM
- DATA - BS 6375 PART 2 PERFORMANCE
- KM 648815 - BS EN 12608-1:2016 / PAS 24:2016
- 5 thermal chambers delivering optimal thermal performance to achieve A+ WER's.
- Low sightline and high performance weather seals for improved insulation and weather protection.
- 24mm and 28mm glazing options to give you the ability to fabricate cost-effective, energy-efficient doors.
- Open in or out master door, with or without a midrail.
- PAS24 and Secured by Design enhanced security options.
- Individually opening sashes for smooth and simple operation.
- Fitter friendly knock-in beads for speedy installation and easier glazing
- Available in 17 colourfoil finishes, which are available on one or boths sides, giving you 34 colour-ways.
EASi-FOLD DOORS - (L) 2610mm x (H) 2220mm
Air Permeability Classification
1
Water Tightness Classification
7A
Resistance to Wind Resistance
A2
Exposure Category in Accordance with BS 6375 Part 1
800 Pa
EASi-FOLD DOORS - (L) 2610mm x (H) 2220mm
Operation Forces
Class 1
Hard Body Impact
Class 2
Vertical Load
Class 2
Closure Against Obstruction
Pass
Resistance to Static Torsion
Class 2
Resistance to Repeated Opening & Closing
4 - 50,000 Cycles
Soft and Heavy Body Impact Load Bearing
Class 2
EASi-FOLD PVCu DOOR SYSTEM
Fabrication and Installation
Fabricated and installed in accordance with the latest issue of the Selecta Systems controlled technical manual.
System Description
The door assemblies are open out, internally beaded with BS EN 1279-2 compliant IGU(s), laminated on one pane to class P1A, with standard threshold and of otherwise fully welded construction. Doors are classified as D.
Hardware
A five point locking (two hooks, two cams, one dead bolt) Yale espagnolette system with two Roto Designo Pivot Hinges and two dog bolts. Yale 3* ASP cylinder, key locking Greenteq handle. Two sliding leaves.
Profiles
Outer frame top, bottom, lock side and hinge side - 1710. Leaf top, bottom, lock side and hinge side - 1715. Steel reinforcing - 1757.2
COLOUR OPTIONS
COLOUR STANDARD COLLECTION
Consisting of the most popular colour combinations.
PREMIUM COLLECTION
Consisting of on-trend, traditional and modern colours and grained effects.
ADVANCE 70 COLOUR OPTIONS
Whilst many favour the bright appearance of brilliant white window frames, the emergence of coloured and more authentically grained profiles has captured the imagination of homeowners.
We offer a wide range of colour options, which have been put together to make the perfect palette for your next project. With 17 colourfoil finishes, available on the external or internal face only or both sides, the collection provides you with 34 colourways.
With modern and traditional shades complimented with authentic wood like finishes, colourfoil adds that finishing touch to any property. Our colour collections provide you with a fantastic palette of colour options for your next project, whatever the style, period or location.
Grained or Smooth? What is the difference?
LOOKING TO OFFER MORE COLOUR OPTIONS?
Kolorseal offer a comprehensive palette of colours for customers who want something different
Manufacture our range of products in virtually any colour you can imagine!
We have teamed up with award winning colour coating specialist, Kolorseal Ltd, meaning we can now offer our fabrication partners the chance to manufacture their range of products in virtually any colour you can imagine.
We believe with consumers now looking to personalise their homes to reflect their lifestyles, colour is an aspect that will give you an advantage in a fiercely competitive market. It is a huge selling point to offer, that will put our fabrication partners ahead of their competitors and we believe will inspire homeowners with added value benefits.
Established 20 years ago, Kolorseal provides excellent services with a five day turnaround guarantee. Attention to detail and customer service is paramount for the company, headed up by Deborah Hendry who has extensive knowledge of the sector.
From window and door frames to composite doors and matching rainwater products, Kolorseal can give our fabrication partners that colourful edge.
To keep things simple, visit www.kolorseal.co.uk and mention that you are a Selecta fabricator!
